TOOCAA L2 Specification

TOOCAA L2 Specification

on
Model 10W  20W

Machine Body

Machine Size

645×617×306 mm(25.35×24.29×12.05 inches)

645×617×306 mm(25.35×24.29×12.05 inches)

Machine Body

Work Area

400×395 mm(15.75×15.55 inches)

400×395 mm(15.75×15.55 inches)

Machine Body

Position Accuracy

0.01 mm

0.01 mm

Machine Body

Re-Positioning Accuracy

0.02 mm

0.02 mm

Machine Body

Maximum Engraving Speed



400 mm/s



400 mm/s

Machine Body



Extended Interface



Emergency Stop Interface, General Expansion Interface, Z-Axis Interface



Emergency Stop Interface, General Expansion Interface, Z-Axis Interface

Machine Body

 Protection

 Flame detection, body tilt detection, smart enclosure safety interlock, USB key switch and extendable emergency stop switch.

 Flame detection, body tilt detection, smart enclosure safety interlock, USB key switch and extendable emergency stop switch.

Machine Body

Laser Class



Class 1



Class 1

Machine Body

Materials

 Aluminum + Acrylic

 Aluminum + Acrylic

Machine Body

GW

 19 kg

 19 kg

Machine Body

NW

 17 kg

 17 kg

Machine Body

Input Voltage



100-240V 50-60HZ



100-240V 50-60HZ

Machine Body

Power



72W



108W

Machine Body

Maximum Thickness of One-pass Cutting (basswood boards)



6 mm



10 mm

Laser Module

Laser Source



450 nm - 460 nm Semiconductor laser



450 nm - 460 nm Semiconductor laser

Laser Module

Laser Power



10W



20W

Laser Module

Input Voltage



24V



24V

Laser Module

Spot Size



0.08×0.18 mm



0.15×0.27 mm

Supported Materials

Engraving Materials



Basswood, tung, pine, plywood, beech, walnut, bamboo, MDF, lacquered metal, tinplate, stainless steel, anodised aluminium, dark-coloured glass, slate, ceramics, jade, marble, shale, leather, fabrics, canvas, corrugated cardboard, cardboard, plastics, dark-coloured acrylic (except blue)



Basswood, tung, pine, plywood, beech, walnut, bamboo, MDF, lacquered metal, tinplate, stainless steel, anodised aluminium, dark-coloured glass, slate, ceramics, jade, marble, shale, leather, fabrics, canvas, corrugated cardboard, cardboard, plastics, dark-coloured acrylic (except blue)

Supported Materials

Cutting Materials



Basswood, tung, pine, plywood, beech, walnut, bamboo, MDF, leather, fabric, canvas, corrugated paper, cardboard, plastic, dark acrylic (except blue)



Basswood, tung, pine, plywood, beech, walnut, bamboo, MDF, leather, fabric, canvas, corrugated paper, cardboard, plastic, dark acrylic (except blue)

Supported Materials

Support Software



LightBurn,LaserGRBL



LightBurn,LaserGRBL

Software

Support Operation System



Windows,MacOS



Windows,MacOS

Software

Support Transporting Methods



TF Card, Type-C



TF Card, Type-C

Certification Information

Certificates



IEC60825, EU: CE RED, CE MD, RoHS 2.0, REACH 233

US: FCC SDoC, prop 65, TSCA, FDA Registration



IEC60825, EU: CE RED, CE MD, RoHS 2.0, REACH 233

US: FCC SDoC, prop 65, TSCA, FDA Registration

Adapter

Input



100-240V~50/60Hz 1.5A



100-240V~50/60Hz 3.5A

Adapter

Output



24.0V 3.0A 72.0W



24.0V 10.0A 240.0W
