Quick Start For TOOCAA L2 Air Assist Kit

Quick Start For TOOCAA L2 Air Assist Kit

on

Attention

  1. The product is applicable to the ambient temperature: -20°C---40°C, it is prohibited to use the product under the condition of higher or lower ambient temperature range.
  2. The product is suitable for ambient humidity: less than 90%, it is prohibited to use the product in conditions higher than this ambient humidity.



Assembly Steps

  1. Connect the 6mm air pipe to its adapter.

  1. Pass the 6mm air pipe through the pass-through hole above the exhaust fan.

  1. Insert the 6mm air pipe into its connector through its fixing hole.

Note: After installing the air pipe, please manually move the laser module to the four corners of the working area of the machine to prevent the air pipe from pulling on the laser module when the machine is working, which will lead to the failure of the job.



Disclaimer

  1. Users should abide by the laws and regulations of the country and region where the equipment is located (place of use), abide by professional ethics, and pay attention to safety obligations. It is strictly forbidden to use our products or equipment for any illegal purpose. Our company is not responsible for the relevant legal responsibilities that the violator should bear.
  2. Since each model is different, the actual product may be different from the picture.Please refer to the actual product. The final interpretation right belongs to SHENZHEN EF TECHNOLOGY CO., LIMITED
