how to install and use TOOCAA Laser Module for L2

Posted By elecfreaksnelson on July 2024

Learn about the TOOCAA laser module

TOOCAA Laser Module
Laser Power	2W	10W	20W	40W
Wavelength	655±5nm (Visible Light Wavelength)	455±5nm
Wavelength	1064±1nm (Invisible Light Wavelength)	455±5nm
Adapter specifications	24.0V ⎓ 5.0A 120.0W	24V⎓3.0A 72.0W	24.0V⎓5.0A 120.0W	24.0V⎓10.0A 240.0W
Spot Size	0.03*0.03mm	0.08*0.18mm	0.15*0.27mm	0.13*0.15mm

TOOCAA laser module installation tutorial

Step 1 Turn off the machine power.
TOOCAA Laser Module

Step 2 Pull the tool lock arm upward to open the X-axis motion assembly.

Step 3 Move the laser module down along the carriage.

Step 4 Press the tool lock arm down to secure the laser module.

Step 5 Connect the USB signal cable and tighten the screws.

TOOCAA laser module removal tutorial

Step 1 Turn off the machine power. TOOCAA Laser Module

Step 2 Remove the USB signal cable after unscrewing the screws. TOOCAA Laser Module

Step 3 Pull the tool lock arm upward to open the X-axis motion assembly.

Step 4 Slide the laser module upward along the carriage to remove it. TOOCAA Laser Module

FAQ

1. The laser module cannot be effectively fixed / the laser module is easy to slip

Solution steps:

Step 1 Take out the laser module. TOOCAA Laser Module Step 2 Remove the outer screw and the tool lock arm.

Step 3 Adjust the tightness of the screw inside the tool carriage.
TIPS：Clockwise adjustment is for tightening, and counterclockwise adjustment is for loosening. Please adjust according to the actual situation.

TOOCAA Laser Module
Tighten clockwise

TOOCAA Laser Module
Loosen counterclockwise
